T-BAR 2X4 Grid Frame Light

T-BAR 2X4 Grid Frame Light

Regular price $105.99 USD
Regular price Sale price $105.99 USD
Sale Sold out


Technical Specs

  • Extruded Aluminum with White Finish
  • High quality LED chips provide high efficiency, heat dissipation, stability and lumen maintenance
  • Performance lens assembly delivers unique beam angles and reduce glare
  • Driver/Junction box is separate and connects to the fixture with a 3Ft. Dongle.
  • Driver/Junction box installs on adjacent grid, on top, using your choice of T-Bar bracket or Westgate T-Bar bracket model (ELB-TBAR1)
  • Driver disconnect provided where required to comply with US and Canadian codes
  • Surge protector
  • Multi-Color temperature & Multi-Power (Selectable switch in driver box)
  • Dimmable: 0 ~ 10V Driver for continuous dimming
  • Lumens: 5250LM/6750LM/8100LM
  • Wattage: 35W/45W/54W
  • Voltage: 120-277V
  • Efficacy: 150LPW
  • Power Factor: >0.92
  • Maximum Ambient Temperature: -22°F to 104°F
  • Color Rendering Index: CRI ≥ 80
  • Color Temp: 3000K/4000K/5000K
  • Lifespan: 50,000 hours
  • 5-year warranty
  • IP Rating: IP20 Indoor use only
